Primus L - Bridge-Type Coordinate Measuring Machines

MORA Measuring Machine Type:

PRIMUS L 152515

---



Our Primus L bridge-type measuring machine features a compact and stable design.
The moving mass is reduced thanks to the elevated guide axis. This allows a larger measuring range on the remaining axes without compromising dynamics or accuracy.
Like the Primus model, the Primus L is equipped with high-precision air bearings and dynamic drives on all axes.
The high-resolution scale system, combined with a powerful controller, guarantees exceptional accuracy.

 .



1. Bridge-type machine for CNC operation.

2. Granite structure with exceptionally high rigidity.

3. High-precision natural stone guideways.

4. The use of low-friction air cushion bearings ensures smooth and low-vibration movement.

5. High movement speed.

6. Non-contact measuring system for high-precision data acquisition.



Measurement Range:

• X 1500 mm (width)
• Y 2500 mm (length)
• Z 1500 mm (height)



Overall Dimensions:

• X 2745 mm (width)
• Y 3820 mm (length)
• Z 4700 mm (height)



Technical Data:

• Weight: 11,000 kg
• Max. table load: Not applicable
• Spatial movement speed: 350 mm/s
• Acceleration: 1380 mm/s²



Accuracy Standard:

• MPEE = 2,9 + L / 300 µm
• MPEp = 2,9 µm



L = Measuring length in mm — Acceptance testing according to ISO 10360-2



Temperature and Air Conditions:

• Temperature: 20 °C ± 2 °C
• Clean and dry compressed air: minimum 6 bar



Control System:

• CNC - 3 axes
• Includes multifunction joystick controls
• Electrical power: 2500 VA 90–240 V ±10%
• Frequency: 50/60 Hz
